A filter press is a batch operation, fixed volume piece of equipment ranging from .01-600 ft3 that separates liquids and solids using pressure filtration. A slurry is pumped into the filter press and dewatered under pressure. A filter press can be used for process, water and wastewater treatment in a variety of different industries and applications.
A filter press has four main components:
Frame: The steel frame acts as a clamping device for the filter plates. (A)
Filter Plates: A filter cake forms in the chambers between filter plates. (B)
Manifold: Our standard manifold consists of piping and valves which control the slurry inlet and connect the four corner filtrate discharge ports into a common discharge pipe. (C)
Filter Cloth: A cloth filter that is attached to both sides of a filter plate. Solids build up on cloth to form a filter cake, separating liquids from solids.
Model | Size | MM | No | Moc | Cake Vol. Holding Cap | Filtration Area | Opr.Pr Bars | Max. Test Pr Bars |
Tightening Mechanism |
Req. Floor Area |
Bare Wg. KgS |
12” *12” 12” *12” 18” *18” 18” *18” 24"x24" 24"x24" 24"x24" 24"x24" 30"x30" 30"x30" 30"x30" 30"x30" 36"x36" 36"x36" 36"x36" 36"x36" |
320 320 470 470 630 630 630 630 700 700 700 700 |
11 17 17 23 23 23 29 29 29 29 35 35 35 35 41 41 |
PP PP PP PP PP PP PP PP PP PP PP PP PP PP PP PP |
24 Ltr 236 Ltr 290 Ltr 160 Ltr 290 Ltr 290 Ltr 360 Ltr 360Ltrs 530 Ltr 530 Ltr 635 Ltr 635 Ltr 930Ltr 930Ltr 10851tr 10851tr |
1.62M3 2.43 m2 6.20 m2 8.26 m2 15.59 m2 15.59 m2 19.49 m2 19.49 m2 30.10 m2 31.10m2 37.32 m2 37.32 m2 54.50 m2 54.50 m2 63.50 m2 63.50 m2 |
2.03.0 2.0-3.0 4.0-5.0 4.0-5.0 4.0-5.0 4.0-5.0 4.0-5.0 4.0-5.0 4.0-5.0 5.0-6.0 4.0-5.0 5.0-6.0 4.0-5.0 5.0-6.0 4.0-5.0 5.0-6.0 |
3.0 3.0 5.0 5.0 5.0 5.0 5.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 |
Manual Manual Manual Manual Manual Manual Manual Hydraulic Motorized Hydraulic Motorized Hydraulic Motorized Hydraulic Motorized Hydraulic Motorized Hydraulic Motorized Hydraulic Motorized Hydraulic Motorized Hydraulic Motorized |
2.5xO.9 2.5xO.9 1.8xO.7 2.1xO.9 2.2xO.9 2.5xO.9 2.5xO.9 2.5xO.9 2.7xO.9 2.7xO.9 3.2xO.9 3.2xO.9 3.6x1 .1 3.6x1 .1 4.0x1.1 4.0x1.1 |
200 230 425 500 990 1060 1090 1160 2300 2450 2900 3050 3000 3000 3200 3400 |
